GENERAL OVERVIEW

Horwin ek1 is developed for daily commute with a modern design, muscular vehicle body lines, automobile class coating technology in pearlescent lacquer, brilliant colors and a combination of fashion and luxury. horwin started a vision of overall design and r&d based on big data analysis, to develop vehicles for all customers and to meet their light travel requirement.

45 km/h

Max. Speed

70 km

Max. Range

72v

Battery

HIGH POWER HUB MOTOR

VISIBLE STRONG DRIVING FORCE

HORWIN EK1 is equipped with high performance hub motor of 2800W. The motor has high energy exchange efficiency with low power consumption and boosts instantaneously super driving force.

HIGH VOLTAGE

INTELLIGENT LITHIUM BATTERY

HORWIN EK1 is equipped with 72V high voltage intelligent lithium battery. With 40Ah volume, the max range reaches 90km. The SOC monitoring system and modern BMS can effectively reduce failures and provide multiple protection.

INTELLIGENT THREE
LENSES LED HEADLIGHT

Automobile class intelligent LED headlight with high intensity light source cutting through the darkness of the night and an automatic light switch-off delay guarantee your safety during driving.

REVERSING POWER one key for reversing.

The R key can easily help you move the vehicle with reversing power.

MODERN COCKPIT for a complete overview.

The LCD display shows all kind of driving information, driving data is available at anytime. The display-colours are green, blue or yellow and depend on the speed you are driving. This is the perfect combination of fashion and technology.

VACUUM TYRES so no more breakdowns.

The vacuum tyres fitted to the EK1 boast outstanding adherence to the road surface. They are breakdown-proof, wear-resistant and have a longer life than ordinary tyres. A perfect combination of safety and comfort.

The high-strength light-metal wheel hubs are made of aluminium alloy. They give the front and rear wheels outstanding stability and resilience but are nevertheless relatively lightweight.

HYDRAULIC SUSPENSION for a comfortable driving, regardless of the road.

The EK1 scooter is fitted with twin hydraulic shock absorbers at the front and rear. They offer the rider an outstanding riding experience – regardless of the road conditions.

LARGE CAPACITY SEAT TRUNK for large storage capacity.

The large storage compartment under the seat can easily hold your daily necessities, such as helmets and backpacks. That solves your problems at your daily trips.
